• Country
• United States of America (USA)

• Manufacturer / Brand
• Amrad Corporation; Medford Hillside (MA)

• Year
• 1927

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 32629

• • alternative name: American Radio & Research

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• 226 226 226 227 226 171A unknown_Tube

• Main principle
• TRF without regeneration; Neutrodyne

• Tuned circuits
• 4 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• -Loudspeaker incorporated, but system not known.

• Material
• Wooden case

• from Radiomuseum.org
• Model: Berwick AC6C - Amrad Corporation; Medford

• Shape
• Console, Lowboy (legs < 50 %).

• Notes

• Single dial tuning control.

• Price in first year of sale
• 295.00 $

• External source of data
• Ernst Erb

• Source of data
• Radio Collector`s Guide 1921-1932

• Circuit diagram reference
• Rider's Perpetual, Volume 1 = 1931/1934 (for 1919-1931)

• Mentioned in
• Collector's Guide to Antique Radios 4. Edition

• Literature/Schematics (1)
• Radio Manufacturers of the 1920s, Vol 1 (p.50)
