Amroh NV Radio: Handy Sound Master HS256 [R-Player] ID = 184814 640x375
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1956–1958 | Category: Sound/Video Recorder and/or Player | ||||
| Valves / Tubes | 3: PCC85 PCL82 EM34 |
|---|
| Main principle | Audio-Amplification; 3 AF stage(s) |
|---|---|
| Wave bands | - without |
| Details | Tape Recorder |
| Power type and voltage | Alternating Current supply (AC) / 220 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 13 cm = 5.1 inch |
| Power out | 2 W (unknown quality) |
| from Radiomuseum.org | Model: Handy Sound Master HS256 - Amroh NV Radio Bulletin |
| Material | Leather / canvas / plastic - over other material |
| Shape | Tablemodel, low profile (big size). |
| Dimensions (WHD) | 350 x 170 x 250 mm / 13.8 x 6.7 x 9.8 inch |
| Notes | Tape recorder 19 cm/s, bias/erase 37.65 kHz, frequency range up to 10 kHz, combined Amroh record-play-erase head, 1 AC motor. |
| Net weight (2.2 lb = 1 kg) | 7.2 kg / 15 lb 13.7 oz (15.859 lb) |
| Price in first year of sale | 348.00 Dfl |
| Literature/Schematics (1) | -- Original-techn. papers. |
Model page created by John Hupse † 28.9.20. See "Data change" for further contributors.
