Angel Boy's Radio TR-25
Angel (Arrow Trading Co.); New York, NY
- United States of America (USA)
- Manufacturer / Brand
- Angel (Arrow Trading Co.); New York, NY
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- Number of Transistors
- Main principle
- TRF with diode detector; 2 AF stage(s); Reflex
- Tuned circuits
- 1 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / 1 x 9 Volt
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
- Power out
- 0.05 W (unknown quality)
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Angel Boy's Radio TR-25 - Angel Arrow Trading Co.; New
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 62 x 90 x 28 mm / 2.4 x 3.5 x 1.1 inch
Available in many colors. Similar to the Globe Boy's Radio.
Reflex stage 3-stage (1HF; 2NF)
Durch Reflexstufe 3-stufig (1HF; 2NF)
Made in Japan
- Net weight (2.2 lb = 1 kg)
- 0.2 kg / 0 lb 7 oz (0.441 lb)
- Mentioned in
- Transistor Radios 1954-68 (p.73)
- Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
