- Country
- Spain
- Manufacturer / Brand
- Anglo Española de Electricidad (AEESA); Barcelona
- Year
- 1960 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 186773
-
- alternative name: Sdad. Anglo Esp. de El. || Sociedad Anglo
- Brand: AEESA
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 472.5 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- AC/DC-set / 125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 2 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 71-DA - Anglo Española de Electricidad
- Dimensions (WHD)
- 360 x 240 x 190 mm / 14.2 x 9.4 x 7.5 inch
- Notes
- Bandas: Normal de 188 a 545 mts. Corta de 50 a 167 mts. Extracorta de 1607 a 50 mts. Cosumo: 25 a 125v.
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by Marcelino Iniesta Fernandez. See "Data change" for further contributors.
