Junior Cadre

Antena; Paris

Data
Forum
Pictures
Collections

  • Year
  • 1954
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 303443

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave and 2 x Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 11 cm = 4.3 inch
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Junior Cadre - Antena; Paris
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 370 x 235 x 190 mm / 14.6 x 9.3 x 7.5 inch
  • Notes

  • 4 gammes d'ondes dont 1 bande étalée (BE) de 47 a 51 m. Antenne cadre ferrite incorporée orientable. Ébénisterie à oreilles.

    Modèle similaire au Junior d'annee 1955, mais avec bouton pour l'orientation de l'antenne sur le dos.

    Le jeu de lampes n'est pas certain.

  • Net weight (2.2 lb = 1 kg)
  • 4.5 kg / 9 lb 14.6 oz (9.912 lb)
  • Price in first year of sale
  • 17,500.00 FRF
  • Mentioned in
  • - - Manufacturers Literature (Tarif au 01.07.1954)
  • Author
  • Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
