• Country
• France

• Manufacturer / Brand
• Arco Jicky, Le Matériel Radioélectrique, CFR (C.F.R., Compagnie Française de Radio); Paris

• Year
• 1956

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 131849

• Number of Tubes
• 5

• Valves / Tubes
• 12BE6 12BA6 12AV6 50B5 35W4

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• AC/DC-set / 110 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10.5 cm = 4.1 inch

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Jicky Sensation [tous courants] - Arco Jicky, Le Matériel

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 245 x 155 x 110 mm / 9.6 x 6.1 x 4.3 inch

• Notes

• 3 gammes d'ondes: BE, PO, GO. Cadre incorporée.

• Net weight (2.2 lb = 1 kg)
• 1.8 kg / 3 lb 15.4 oz (3.965 lb)

• Price in first year of sale
• 13,975.00 FRF

• Literature/Schematics (1)
• Le grand livre de la TSF (Doctsf Ref 19900)

• Literature/Schematics (2)
• -- Original prospect or advert (Publicité 1956)

• Author
• Model page created by Hugo Sneyers. See "Data change" for further contributors.

• Other Models

• Here you find 108 models, 84 with images and 25 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
