Arvin 40A "Mighty Mite"

Arvin 40A 'Mighty Mite' ; Arvin, brand of (ID = 1329562) Radio

Arvin 40A 'Mighty Mite' ; Arvin, brand of (ID = 2381229) Radio
Arvin 40A 'Mighty Mite' ; Arvin, brand of (ID = 1392358) Radio Arvin 40A 'Mighty Mite' ; Arvin, brand of (ID = 1744478) Radio
Arvin 40A 'Mighty Mite' ; Arvin, brand of (ID = 1845358) Radio Arvin 40A 'Mighty Mite' ; Arvin, brand of (ID = 1845359) Radio
Arvin 40A 'Mighty Mite' ; Arvin, brand of (ID = 1845360) Radio
Use red slider bar for more.
Arvin 40A 'Mighty Mite' ; Arvin, brand of (ID = 1392358) Radio
Arvin, brand of: Arvin 40A "Mighty Mite" [Radio] ID = 1392358 933x1237
Select picture or schematic to display from thumbnails on the right and click for download.
For model Arvin 40A "Mighty Mite", Arvin, brand of Noblitt-Sparks Industries:
Image courtesy of Mark V. Stein for Radiomuseum.org use only. From Table Top Radios Volume 1.

Country:  United States of America (USA)
Manufacturer / Brand:  Arvin, brand of Noblitt-Sparks Industries
Year: 1938/1939 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 2: 25B8GT 70L7GT
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown)
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 115 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Arvin 40A "Mighty Mite" - Arvin, brand of Noblitt-Sparks
Material Metal case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Notes



Colours and material:

Metal

model 40: brown finish

model 40A: ivory finish

External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 11 = ca. 1940 and before
Mentioned in Table Top Radios Vol. 1 Stein 98 (page 37.)
Literature/Schematics (1) Table Top Radios Vol. 4 Stein 2003 (page 50.)
