For model 444A Ch= RE-200 ivory, Arvin, brand of Noblitt-Sparks Industries

Country:  United States of America (USA)
Manufacturer / Brand:  Arvin, brand of Noblitt-Sparks Industries
Year: 1946/1947 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 12SA7 12SQ7 50L6GT 35Z5GT
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 117-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out
from Radiomuseum.org Model: 444A Ch= RE-200 [ivory] - Arvin, brand of Noblitt-Sparks
Material Metal case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 6.5 x 5.25 x 4 inch / 165 x 133 x 102 mm
Notes Coil antenna. This model Arvin 444 was also produced in Canada and is existing in Brown and in Ivory (enamel on metal). See also models 402 and 402A from 1939/40 and others of that same kind.
Net weight (2.2 lb = 1 kg) 5 lb 0 oz (5 lb) / 2.270 kg
Price in first year of sale 10.55 $
Collectors' prices
External source of data Ernst Erb
Source of data Collector's Guide to Antique Radios 4. Edition
Circuit diagram reference Rider's Perpetual, Volume 15 = 1947 and before
Mentioned in Radio College of Canada, Individual Circuit Service, 1927-1953
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 1, Folder 461-3)
Literature/Schematics (2) Radio Retailing (Radio & Television R.) (January 1946 page 36. August 1946 page 2. February 1947 page 59.)
