124P

124P; Asa, Turku (ID = 1345468) Radio

124P; Asa, Turku (ID = 1345470) Radio
124P; Asa, Turku (ID = 1262407) Radio 124P; Asa, Turku (ID = 1335154) Radio
124P; Asa, Turku (ID = 1335155) Radio 124P; Asa, Turku (ID = 1335156) Radio
124P; Asa, Turku (ID = 1335157) Radio 124P; Asa, Turku (ID = 1335158) Radio
124P; Asa, Turku (ID = 1335160) Radio 124P; Asa, Turku (ID = 1335295) Radio
124P; Asa, Turku (ID = 1361357) Radio 124P; Asa, Turku (ID = 1363180) Radio
Use red slider bar for more.
124P; Asa, Turku (ID = 1262407) Radio
Asa, Turku: 124P [Radio] ID = 1262407 922x692
Select picture or schematic to display from thumbnails on the right and click for download.
For model 124P, Asa, Turku

Country:  Finland
Manufacturer / Brand:  Asa, Turku
Year: 1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: DF96 DK96 DF96 DAF96 DL96
Main principle Superheterodyne (common); ZF/IF 486 kHz
Tuned circuits 8 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Storage and/or dry batteries / 1,4; 2 & 90 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
Power out
from Radiomuseum.org Model: 124P - Asa, Turku
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 500 x 350 x 260 mm / 19.7 x 13.8 x 10.2 inch

Model page created by Timo Rantasaari. See "Data change" for further contributors.



All listed radios etc. from Asa, Turku
Here you find 296 models, 209 with images and 126 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
