139P

139P; Asa, Turku (ID = 1331807) Radio

139P; Asa, Turku (ID = 1331809) Radio
139P; Asa, Turku (ID = 1262575) Radio 139P; Asa, Turku (ID = 1341432) Radio
139P; Asa, Turku (ID = 1341433) Radio 139P; Asa, Turku (ID = 1341434) Radio
139P; Asa, Turku (ID = 1341435) Radio 139P; Asa, Turku (ID = 1341436) Radio
139P; Asa, Turku (ID = 1341437) Radio
Use red slider bar for more.
139P; Asa, Turku (ID = 1262575) Radio
Asa, Turku: 139P [Radio] ID = 1262575 922x692
Select picture or schematic to display from thumbnails on the right and click for download.
For model 139P, Asa, Turku

Country:  Finland
Manufacturer / Brand:  Asa, Turku
Year: 1957 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: DF96 DK96 DF96 DAF96 DL96
Main principle Superheterodyne (common); ZF/IF 485 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Storage and/or dry batteries / 1,5; 2 & 90 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
Power out
from Radiomuseum.org Model: 139P - Asa, Turku
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 520 x 330 x 230 mm / 20.5 x 13 x 9.1 inch

Model page created by Timo Rantasaari. See "Data change" for further contributors.
