For model Minivisio Asavisio 3662, Asa, Turku

Country:  Finland
Manufacturer / Brand:  Asa, Turku
Year: 1973 Category: Television Receiver (TV) or Monitor
Valves / Tubes 1:
Semiconductors (the count is only for transistors) 36:
Main principle Superheterodyne (common)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Line / Storage batteries (perhaps also batteries) / 220 / 12 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Minivisio Asavisio 3662 - Asa, Turku
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 380 x 290 x 230 mm / 15 x 11.4 x 9.1 inch
Notes

Tragbares Schwarz-Weiss-Gerät mit 31 cm-Bildröhre, volltransistorisiert mit 2 ICs, 36 Transistoren, 32 Dioden.

Frontlautsprecher 13 x 8 cm. Schwenkbare Doppelteleskopantenne. Anschlussmöglichkeit für Aussenantenne, Zweitlautsprecher, Tonbandgerät/Plattenspieler. Traggriff aus Aluminium.

Akku-Box mit Ladegerät (7,5 Ah, ca. 5 h Betriebszeit) zur Montage an der Geräteunterseite als Zubehör erhältlich.

Gehäuse aus rotem, weissem oder olivgrünem Kunststoff.

Net weight (2.2 lb = 1 kg) 8.7 kg / 19 lb 2.6 oz (19.163 lb)
Price in first year of sale 795.00 FIM
Source of data -- Original prospect or advert

Model page created by Tapio Karilainen. See "Data change" for further contributors.
