Sesam 495M

Sesam 495M; Asa, Turku (ID = 1010952) Radio Sesam 495M; Asa, Turku (ID = 1010953) Radio
Sesam 495M; Asa, Turku (ID = 1010954) Radio Sesam 495M; Asa, Turku (ID = 1010955) Radio
Sesam 495M; Asa, Turku (ID = 1010956) Radio Sesam 495M; Asa, Turku (ID = 1010957) Radio
Sesam 495M; Asa, Turku (ID = 1010958) Radio Sesam 495M; Asa, Turku (ID = 1010959) Radio
Sesam 495M; Asa, Turku (ID = 1010960) Radio Sesam 495M; Asa, Turku (ID = 1010961) Radio
Use red slider bar for more.
Sesam 495M; Asa, Turku (ID = 1010952) Radio
Asa, Turku: Sesam 495M [Radio] ID = 1010952 922x692
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sesam 495M, Asa, Turku

Country:  Finland
Manufacturer / Brand:  Asa, Turku
Year: 1949 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: DK21 DF21 DAC21 DL21
Main principle Superheterodyne (common); ZF/IF 485 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Dry Batteries / 1,5 & 95 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out
from Radiomuseum.org Model: Sesam 495M - Asa, Turku
Material Wooden case
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 310 x 245 x 135 mm / 12.2 x 9.6 x 5.3 inch

Model page created by Timo Rantasaari. See "Data change" for further contributors.



All listed radios etc. from Asa, Turku
Here you find 296 models, 209 with images and 126 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
