AS5000E

AS5000E; ASC; Hösbach und (ID = 127356) Radio AS5000E; ASC; Hösbach und (ID = 1831941) Radio
AS5000E; ASC; Hösbach und (ID = 2227307) Radio
Use red slider bar for more.
AS5000E; ASC; Hösbach und (ID = 127356) Radio
ASC; Hösbach und: AS5000E [Radio] ID = 127356 933x302
Select picture or schematic to display from thumbnails on the right and click for download.
For model AS5000E, ASC; Hösbach und Aschaffenburg

Country:  Germany
Manufacturer / Brand:  ASC; Hösbach und Aschaffenburg
Year: 1978 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
schematic requested
Main principle Superheterodyne (common)
Wave bands FM Broadcast Band Only
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: AS5000E - ASC; Hösbach und Aschaffenburg
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 430 x 110 x 345 mm / 16.9 x 4.3 x 13.6 inch
Notes PLL Tuner mit Digitalanzeige und 7 Stationstasten
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in Funkschau (21/1978, S. 1003)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Michael Schlör. See "Data change" for further contributors.
