UHF Modulator UM 1287

Astec International Limited; Pasig

  • Year
  • 1983 ??
  • Category
  • Radio module post 1925 (not a part, not a key)
  • Radiomuseum.org ID
  • 277565

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Details
  • Converter
  • Power type and voltage
  • Powered by external power supply or a main unit. / DC 5 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: UHF Modulator UM 1287 - Astec International Limited;
  • Shape
  • Chassis only or for «building in»
  • Notes
  • ASTEC UHF - Modulator ( Kanal 36 )

  • Author
  • Model page created by Reinhard Keins. See "Data change" for further contributors.
