500-GF

500-GF; Astor brand, Radio (ID = 704737) Radio
500-GF; Astor brand, Radio (ID = 2258802) Radio 500-GF; Astor brand, Radio (ID = 2253426) Radio
500-GF; Astor brand, Radio (ID = 2253427) Radio 500-GF; Astor brand, Radio (ID = 2266713) Radio
500-GF; Astor brand, Radio (ID = 2266716) Radio 500-GF; Astor brand, Radio (ID = 2253648) Radio
Use red slider bar for more.
500-GF; Astor brand, Radio (ID = 2258802) Radio
Astor brand, Radio: 500-GF [Radio] ID = 2258802 864x710
Select picture or schematic to display from thumbnails on the right and click for download.
For model 500-GF, Astor (brand), Radio Corporation Pty., Ltd.; Melbourne

Country:  Australia
Manufacturer / Brand:  Astor (brand), Radio Corporation Pty., Ltd.; Melbourne
alternative name

Radio Corp.of Australia
Year: 1938/1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 1A7G 1N5G 1N5G 1H5G 1A5G
schematic requested
Main principle Superheterodyne (common); ZF/IF 456 kHz; 2 AF stage(s)
Tuned circuits 8 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 90 & 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 500-GF - Astor brand, Radio Corporation
Material Bakelite case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Price in first year of sale 19.00 Aus£
Circuit diagram reference Australian Official Radio Service Manual Vol. I I

Model page created by Stuart Irwin. See "Data change" for further contributors.



All listed radios etc. from Astor (brand), Radio Corporation Pty., Ltd.; Melbourne
Here you find 825 models, 331 with images and 343 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.


Collection of a member from AUS
