Baby BR

Baby BR; Astor brand, Radio (ID = 2016057) Radio

Baby BR; Astor brand, Radio (ID = 2016058) Radio

Baby BR; Astor brand, Radio (ID = 2056664) Radio
Baby BR; Astor brand, Radio (ID = 962885) Radio Baby BR; Astor brand, Radio (ID = 962886) Radio
Use red slider bar for more.
Baby BR; Astor brand, Radio (ID = 962885) Radio
Astor brand, Radio: Baby BR [Radio] ID = 962885 698x517
Select picture or schematic to display from thumbnails on the right and click for download.
For model Baby BR, Astor (brand), Radio Corporation Pty., Ltd.; Melbourne:
Ebay #170616732311

Country:  Australia
Manufacturer / Brand:  Astor (brand), Radio Corporation Pty., Ltd.; Melbourne
alternative name

Radio Corp.of Australia
Year: 1941 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: 12B8GT 6V6G 6X5GT
Main principle TRF with regeneration; 1 AF stage(s)
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Baby BR - Astor brand, Radio Corporation
Material Moulded (Bakelite or Plastics)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Price in first year of sale 11.00 Aus£
Circuit diagram reference Australian Official Radio Service Manual Vol. IV
Literature/Schematics (1) Mingay's Radio Diagram & I.F. Index

Model page created by Stuart Irwin. See "Data change" for further contributors.



All listed radios etc. from Astor (brand), Radio Corporation Pty., Ltd.; Melbourne
Here you find 822 models, 300 with images and 340 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
