DLP

DLP ; Astor brand, Radio (ID = 428724) Radio
DLP ; Astor brand, Radio (ID = 428723) Radio DLP ; Astor brand, Radio (ID = 450015) Radio
DLP ; Astor brand, Radio (ID = 716012) Radio DLP ; Astor brand, Radio (ID = 716011) Radio
Use red slider bar for more.
DLP ; Astor brand, Radio (ID = 428723) Radio
Astor brand, Radio: DLP [Radio] ID = 428723 400x290
Select picture or schematic to display from thumbnails on the right and click for download.
For model DLP, Astor (brand), Radio Corporation Pty., Ltd.; Melbourne

Country:  Australia
Manufacturer / Brand:  Astor (brand), Radio Corporation Pty., Ltd.; Melbourne
alternative name

Radio Corp.of Australia
Year: 1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 2: 6BE6 6BM8
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Tuned circuits 4 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: DLP - Astor brand, Radio Corporation
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Notes

Available in 14 colours: Maroon, Pale Blue, Ivory, Pastel Blue, Grey, Pastel Green, Walnut, Pink, Dark Red, Turquoise, Coral, Dark Green, Black & Light Red.

Solid state rectifier.

Collectors' prices
Source of data -- Schematic
Mentioned in Silicon Chip Magazine, October 2016, Page 92.
Literature/Schematics (1) - - Manufacturers Literature (Astor Technical Bulletin DLP-1, 10/12/1956.)
Literature/Schematics (2) J.R. Publications Radio Service Handbook (R.V. Series Vol. 1, 1963, Page A32.)

Model page created by Peter Hughes. See "Data change" for further contributors.
