Transistor FRW

Transistor FRW; Astor brand, Radio (ID = 2051755) Radio

Transistor FRW; Astor brand, Radio (ID = 2051756) Radio

Transistor FRW; Astor brand, Radio (ID = 2051757) Radio
Transistor FRW; Astor brand, Radio (ID = 2439792) Radio
Use red slider bar for more.
Transistor FRW; Astor brand, Radio (ID = 2439792) Radio
Astor brand, Radio: Transistor FRW [Radio] ID = 2439792 1400x1237
Select picture or schematic to display from thumbnails on the right and click for download.
For model Transistor FRW, Astor (brand), Radio Corporation Pty., Ltd.; Melbourne:
Service manual cover.

Country:  Australia
Manufacturer / Brand:  Astor (brand), Radio Corporation Pty., Ltd.; Melbourne
alternative name

Radio Corp.of Australia
Year: 1960/1961 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: 2N486 2N484 2N484 TS2_STC or. TS3_STC or. TS3-Z 2N632 2N632 1N295
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 4 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.75 inch = 7 cm
Power out 0.1 W (unknown quality)
from Radiomuseum.org Model: Transistor FRW - Astor brand, Radio Corporation
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Notes
  • Four dial scales to suit NSW, VIC/TAS, QLD & SA/WA.
  • Earpiece jack socket.
  • Rola Type 2 C (15Ω) loudspeaker.
  • 4 x 1.5V AA batteries.
  • Price includes batteries.
  • Colours available: Tan/White, Charcoal/White, Lime/White, Cherry Red/White, Chartreuse/White & Dark Green/White.
Price in first year of sale 27.30 AUS £
Literature/Schematics (1) - - Manufacturers Literature (Astor Technical Bulletin FRW-1, 12/7/1960. (Also at KevinChant.com))
Literature/Schematics (2) J.R. Publications Transistor Radio Service Handbook (Vol.1, 1960, Page A18)
Literature/Schematics (3) J.R. Publications Transistor Radio Service Handbook (A Series Handbook, Page A57.)
Literature/Schematics (4) Mingay's Radio Electrical Weekly Price Service (REWPS) (Feb 1961.)
