For model GPM, Astor (brand), Radio Corporation Pty., Ltd.; Melbourne:
Not original speaker cloth

Country:  Australia
Manufacturer / Brand:  Astor (brand), Radio Corporation Pty., Ltd.; Melbourne
alternative name

Radio Corp.of Australia
Year: 1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6BE6 6BH5 6BD7 6M5 6V4
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 200-220; 221-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: GPM - Astor brand, Radio Corporation
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Notes

Cabinet colours available in Brown, Maroon, Pale Blue, Red, Ivory, Powder Blue, Fawn, Light Grey & Green.

Price in first year of sale 21.00 AUS £
Circuit diagram reference Australian Official Radio Service Manual Vol. XIV
Literature/Schematics (1) - - Manufacturers Literature (Astor Technical Bulletin GPM-1, 22/9/1955.)
Literature/Schematics (2) Australian Official Radio Service Manual AORSM (Volume 14, 1956, Page 48.)
Literature/Schematics (3) J.R. Publications Television Service Handbook (R.V. Series Vol. 1, Page A44.)

Model page created by Stuart Irwin. See "Data change" for further contributors.
