• Year
  • 1929
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 74731

 Technical Specifications

  • Number of Tubes
  • 7
  • Main principle
  • TRF without regeneration; Screengrid 1926-1935
  • Tuned circuits
  • 4 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Storage and/or dry batteries
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 67 Battery Console - Atwater Kent Mfg. Co.;
  • Shape
  • Console with any shape - in general
  • Notes
  • Uses panel (chassis) 67C early or late.

  • Circuit diagram reference
  • Rider's Perpetual, Volume 3 = 1933 and before
