For model Amateur combinations using AK components, Atwater Kent Mfg. Co.; Philadelphia, USA:
By courtesy of Del Tysdal: 1 tube radio consisting of Mounted Variocoupler 3731 and Detector Unit 3902 on a breadboard (not by AK). Amateur made, not factory made.

Country:  United States of America (USA)
Manufacturer / Brand:  Atwater Kent Mfg. Co.; Philadelphia, USA
Year: 1922–1929 Category: Broadcast Receiver - or past WW2 Tuner
Details
Loudspeaker
Power out
from Radiomuseum.org Model: Amateur combinations using AK components - Atwater Kent Mfg. Co.;
Notes These are not factory made sets.
There had been some recommendations in the literature for amateurs how to construct a receiver using certain Atwater Kent (AK) components. One was known as "The DX", which came from "the Newark Sunday Call", not from AK.
All data go into the picture legend, NOT into this Model sheet!
Literature/Schematics (1) A.Atwater Kent, The Man, 2002 (p.29)

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
