World Recevier RA65; AudioTon Grünwald (ID = 695729) Radio
AudioTon Grünwald: World Recevier RA65 [Radio] ID = 695729 768x535
Select picture or schematic to display from thumbnails on the right and click for download.
For model World Recevier RA65, AudioTon (Grünwald) Electronics; Wien

Country:  Austria
Manufacturer / Brand:  AudioTon (Grünwald) Electronics; Wien
Year: 1994 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast, more than 2 SW bands plus FM or UHF.
Details
Power type and voltage Storage and/or dry batteries / 2 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4.5 cm = 1.8 inch
Power out
from Radiomuseum.org Model: World Recevier RA65 - AudioTon Grünwald Electronics;
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 130 x 73 x 25 mm / 5.1 x 2.9 x 1 inch
Notes 1 IC. Sony CXA1191M.

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
