• Country
• United States of America (USA)

• Manufacturer / Brand
• Autocrat Radio Co.; Chicago (IL)

• Year
• 1939 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 33597

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 2

• Valves / Tubes
• 6A7 76

• Main principle
• RF Converter/Adapter (not voltage converter)

• Tuned circuits
• 1 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 110 Volt

• Loudspeaker
• - - No sound reproduction output.

• from Radiomuseum.org
• Model: Phono-Oszillator 213 - Autocrat Radio Co.; Chicago IL

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 11 = ca. 1940 and before
