• Country
• Great Britain (UK)

• Manufacturer / Brand
• AVO Ltd.; London

• Year
• 1970 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 212166

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 2

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Storage and/or dry batteries / 1,5 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Bakelite case

• from Radiomuseum.org
• Model: AvoMinor Mk.v - AVO Ltd.; London

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 144 x 35 x 93 mm / 5.7 x 1.4 x 3.7 inch

• Notes
• Measurement ranges:
  DC: 100mV, 2.5, 10, 25, 100, 250, 1000 V;
  AC: 10, 25, 100, 250, 1000 V;
  I (DC): 0.1, 1, 10, 100, 1000 mA;
  R ranges are 0-20 k and 0-2 Mohm;
  Ohms/volt: 10k on DC ranges, 1k on AC ranges; Basic meter movement: 60 µA.

• Author
• Model page created by Georges Van Campenhout † 28.4.22. See "Data change" for further contributors.
