D6200

D6200; BASF, Badische (ID = 563506) Radio D6200; BASF, Badische (ID = 1597412) Radio
Use red slider bar for more.
D6200; BASF, Badische (ID = 563506) Radio
BASF, Badische: D6200 [Radio] ID = 563506 807x369
Select picture or schematic to display from thumbnails on the right and click for download.
For model D6200, BASF, Badische Anilin- & Soda-Fabrik; Ludwigshafen:
Original prospekt in 1979.

Country:  Germany
Manufacturer / Brand:  BASF, Badische Anilin- & Soda-Fabrik; Ludwigshafen
Year: 1979 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands FM Broadcast Band Only
Details
Loudspeaker
Power out
from Radiomuseum.org Model: D6200 - BASF, Badische Anilin- & Soda-
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 425 x 100 x 360 mm / 16.7 x 3.9 x 14.2 inch
Notes HiFi-Tuner mit Fluoreszenzanzeigen für Frequenz, Feldstärke und Ratio-Mitte. Muting-Schalter. Frequenzgang: 30-15000Hz. Gehäuse: Silber
Net weight (2.2 lb = 1 kg) 8.5 kg / 18 lb 11.6 oz (18.722 lb)
Source of data -- Original prospect or advert

Model page created by Franz Scharner. See "Data change" for further contributors.



All listed radios etc. from BASF, Badische Anilin- & Soda-Fabrik; Ludwigshafen
Here you find 76 models, 74 with images and 12 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
