For model RT21 D46F1, BBC - Brown Boveri; Switzerland:
Original v Handbuch

Country:  Switzerland
Manufacturer / Brand:  BBC - Brown Boveri; Switzerland
Year: 1968 ? Category: Commercial Transmitter & Receiver (TRX not Amateur)
Semiconductors (the count is only for transistors) 1:
Main principle Superheterodyne (common)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Storage and/or dry batteries / 6; 12; 24 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: RT21 D46F1 - BBC - Brown Boveri;
Material Various materials
Shape Chassis only or for «building in»
Dimensions (WHD) 260 x 57 x 190 mm / 10.2 x 2.2 x 7.5 inch
Notes Das Sprechfunkgerät RT21,Type D46F1 arbeitet im Frequenzbereich 440-470MHz. Es arbeitet im Symplex-Einfrequenz- oder im Symplex-Zweifrequenz-Verfahren. Bei Bedarf kann zusätzlich ein Selektivruf eingebaut werden.
Das Gehäuse enthält Sender, Empfänger und den Speiseteil.
Je nach Batteriespannung ist für 6 V-, 12 V- oder 24V- Batterien das entsprechende Speiseteil zu wählen.
Net weight (2.2 lb = 1 kg) 3.8 kg / 8 lb 5.9 oz (8.37 lb)
Source of data -- Original-techn. papers.

Model page created by Rudolf Müller. See "Data change" for further contributors.
