Qualiton Transistor Amplifier AET-230

Qualiton Transistor Amplifier AET-230; Budapesti (ID = 749967) Ampl/Mixer Qualiton Transistor Amplifier AET-230; Budapesti (ID = 749968) Ampl/Mixer
Qualiton Transistor Amplifier AET-230; Budapesti (ID = 1724396) Ampl/Mixer Qualiton Transistor Amplifier AET-230; Budapesti (ID = 1724397) Ampl/Mixer
Qualiton Transistor Amplifier AET-230; Budapesti (ID = 1724408) Ampl/Mixer Qualiton Transistor Amplifier AET-230; Budapesti (ID = 1724421) Ampl/Mixer
Qualiton Transistor Amplifier AET-230; Budapesti (ID = 1725742) Ampl/Mixer Qualiton Transistor Amplifier AET-230; Budapesti (ID = 1725744) Ampl/Mixer
Qualiton Transistor Amplifier AET-230; Budapesti (ID = 1725745) Ampl/Mixer Qualiton Transistor Amplifier AET-230; Budapesti (ID = 1725746) Ampl/Mixer
Use red slider bar for more.
Qualiton Transistor Amplifier AET-230; Budapesti (ID = 749967) Ampl/Mixer
Budapesti: Qualiton Transistor Amplifier AET-230 [Ampl/Mixer] ID = 749967 627x332
Select picture or schematic to display from thumbnails on the right and click for download.
For model Qualiton Transistor Amplifier AET-230, Budapesti Elektroakusztikai Gyár (BEAG), Budapest:
Thanks for Mr.Janka Jenö Hungary!

Country:  Hungary
Manufacturer / Brand:  Budapesti Elektroakusztikai Gyár (BEAG), Budapest
Year: 1973 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) 23: BC109 BC182 BC212 BC301 BC303 2N3055 BFY34
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 40 W (max.)
from Radiomuseum.org Model: Qualiton Transistor Amplifier AET-230 - Budapesti Elektroakusztikai Gy
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 400 x 100 x 300 mm / 15.7 x 3.9 x 11.8 inch
Notes Transistortypes only once listed.
Net weight (2.2 lb = 1 kg) 10 kg / 22 lb 0.4 oz (22.026 lb)
Source of data -- Schematic

Model page created by Peter Bekei. See "Data change" for further contributors.
