Avus LMKU ab F270001
Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim
- Country
- Germany
- Manufacturer / Brand
- Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim
- Year
- 1975 ??
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 285640
Aus dem Servicemanual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 10
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 7 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Avus LMKU ab F270001 - Becker, Max Egon,
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 180 x 42 x 117 mm / 7.1 x 1.7 x 4.6 inch
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
