• Country
• Germany

• Manufacturer / Brand
• Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim

• Year
• 1967–1969

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 27187

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 12

• Semiconductors
• AF106 AF138 AC117 AC125 AC126 AD148 AA112 AA119

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Tuned circuits
• 8 AM circuit(s)     14 FM circuit(s)

• Wave bands
• Broadcast, Short Wave plus FM or UHF.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 5 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Avus UMK [ab Nr. C701356] - Becker, Max Egon,

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 180 x 52 x 150 mm / 7.1 x 2 x 5.9 inch

• Notes
• Halbleiter teilweise mehrfach vorhanden.
  Technische Daten und Ausführung wie Avus UML, jedoch Wellenbereiche UMK und 9 AM-Kreise bei KW.

• Net weight (2.2 lb = 1 kg)
• 1.4 kg / 3 lb 1.3 oz (3.084 lb)

• External source of data
• erb

• Source of data
• Handbuch VDRG 1967/1968 / Radiokatalog Band 2, Ernst Erb
