Europa LMKU 9 Tr.

• Country
• Germany

• Manufacturer / Brand
• Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim

• Year
• 1969/1970

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 27762

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 9

• Semiconductors
• BF185 BF195 BF195 AF138 AF138 AF138 AF138 TAA435 AD161 AD162

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Tuned circuits
• 8 AM circuit(s)     14 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 5 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Europa LMKU [9 Tr.] - Becker, Max Egon,

• Dimensions (WHD)
• 180 x 52 x 150 mm / 7.1 x 2 x 5.9 inch

• Notes
• ICs: 1
  Anschlüsse für Automatikantenne und KW.Adapter.
  Auch als Sonderausführung für 24-V-Betrieb gefertigt. Standardzubehör DM 37.-

• Net weight (2.2 lb = 1 kg)
• 2.7 kg / 5 lb 15.2 oz (5.947 lb)

• Price in first year of sale
• 240.00 DM

• External source of data
• erb

• Source of data
• Handbuch VDRG 1969/1970 / Radiokatalog Band 2, Ernst Erb
