Europa TR; Becker, Max Egon, (ID = 817370) Car Radio
Becker, Max Egon,: Europa TR [Car Radio] ID = 817370 850x605
Select picture or schematic to display from thumbnails on the right and click for download.
For model Europa TR, Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim:
Q: Becker Service-Unterlagen

Country:  Germany
Manufacturer / Brand:  Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim
Year: 1965/1966 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 11: AF106 AF138 AC126 AC125 AC128 AD148 AA119 AA112
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 8 AM circuit(s)     13 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 6 W (unknown quality)
from Radiomuseum.org Model: Europa TR - Becker, Max Egon,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 180 x 52 x 150 mm / 7.1 x 2 x 5.9 inch
Notes Halbleiter teilweise mehrfach vorhanden.
Anschluss für Automatik-Antenne; NF-Teil (180×52×83 mm) schwenkbar an Empfänger angeflanscht oder über Kabel getrennt vom Empfänger einbaubar.
Net weight (2.2 lb = 1 kg) 2.7 kg / 5 lb 15.2 oz (5.947 lb)
Price in first year of sale 385.00 DM
External source of data erb
Source of data Handbuch VDRG 1965/1966 / Radiokatalog Band 2, Ernst Erb
