Grand Prix Serie M; Becker, Max Egon, (ID = 947263) Car Radio
Becker, Max Egon,: Grand Prix Serie M [Car Radio] ID = 947263 933x457
Select picture or schematic to display from thumbnails on the right and click for download.
For model Grand Prix Serie M, Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim:
Becker Grand Prix in Betrieb...

Country:  Germany
Manufacturer / Brand:  Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim
Year: 1975/1976 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 18: BF222 BF495 BF495 BF198 BF198 BF494 BF494 BF198 BF198 BF198 BC238 BC238 BC140 AD156 AD157 BC238 BC238 BC238
schematic requested
Main principle Superhet with RF-stage
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Grand Prix Serie M - Becker, Max Egon,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 180 x 42 x 155 mm / 7.1 x 1.7 x 6.1 inch
Notes Becker Grand Prix hat 5 mechanische Stationsspeicher (2x UKW, KW, MW, LW) und
automatischen Sendersuchlauf dessen Empfindlichkeit in 3 Stufen schaltbar ist.
Klangwaage. Anschluss für Cassette/Tonbandgerät und Automatikantenne.
Net weight (2.2 lb = 1 kg) 1.8 kg / 3 lb 15.4 oz (3.965 lb)
Collectors' prices

Model page created by Bernhard Nagel. See "Data change" for further contributors.
