For model 526-A Ch= R-1, Bendix Radio Division; Baltimore, MD

Country:  United States of America (USA)
Manufacturer / Brand:  Bendix Radio Division; Baltimore, MD
Year: 1946 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12SA7 12SK7 12SQ7 50L6 35Z5
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 105-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out 1.88 W (unknown quality)
from Radiomuseum.org Model: 526-A Ch= R-1 - Bendix Radio Division;
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 11.25 x 7.25 x 7.25 inch / 286 x 184 x 184 mm
Notes Cabinet: brown plastic. "Super Signal" built-in antenna. Beam power output.
Price in first year of sale 22.95 $
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 20 covering 1950
Mentioned in Bendix Service Manual
