K2251 Ch= T20

• Country
• United States of America (USA)

• Manufacturer / Brand
• Bendix Radio Division; Baltimore, MD

• Year
• 1956 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 308803

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 20

• Valves / Tubes
• 6T4 6BK7A 6U8 6CB6 6CB6 6CB6 6AW8 6AU6 6AL5 6AV6 6DG6GT 6CG7 6C4 6S4 6SN7GTB 6CU6 6AX4GT 1B3GT 5U4G 21AUP4A

• Main principle
• Superhet with RF-stage

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: K2251 Ch= T20 - Bendix Radio Division;

• Shape
• Console with any shape - in general

• Notes

• Bendix model K2251  is a 21" b/w TV with US standard VHF tuner channels 2 thru 13, and 14 thru 83 UHF. Equipped with chassis T20, VHF- tuner 258067-5 ,UHF tuner 258067-6  and picture tube 21AUP4A.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 328 Folder 3 dated 9-56)

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.

• Other Models

• Here you find 440 models, 359 with images and 216 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Bendix Radio Division; Baltimore, MD
