• Country
• Germany

• Manufacturer / Brand
• Beyer; Berlin, später Beyerdynamic; Heilbronn

• Year
• 2000 ?

• Category
• Commercial Transmitter (TX not Transceiver)

• Radiomuseum.org ID
• 268545

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Transmitter

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Line plus power jack, mostly with battery or storage battery / AC 230 / DC: 15 Volt

• Loudspeaker
• - - No sound reproduction output.

• from Radiomuseum.org
• Model: CT 30 Best. Nr. 457.035 - Beyer; Berlin, später

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 215 x 43 x 179 mm / 8.5 x 1.7 x 7 inch

• Notes

• Stationärer Sender für Dolmetscher-Anlagen mit den Empfängern FE 30,

  16 wählbare Frequenzen im Bereich 863,025 - 864,975 MHz,
  LCD-Display,
  Schmalband FM mit 8 kHz Hub,
  Sendeleistung 50 mW,
  Eingang: 3 pol. XLR und 6,3 mm Klinke,
  Antennenanschluß über BNC.

• Net weight (2.2 lb = 1 kg)
• 0.950 kg / 2 lb 1.5 oz (2.093 lb)

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by a member from D. See "Data change" for further contributors.
