BR-600

BR-600; Bigston Kyokuyo (ID = 722219) Radio

BR-600; Bigston Kyokuyo (ID = 722220) Radio

BR-600; Bigston Kyokuyo (ID = 722221) Radio
BR-600; Bigston Kyokuyo (ID = 1323798) Radio BR-600; Bigston Kyokuyo (ID = 722222) Radio
BR-600; Bigston Kyokuyo (ID = 1323799) Radio BR-600; Bigston Kyokuyo (ID = 1323800) Radio
BR-600; Bigston Kyokuyo (ID = 1323803) Radio BR-600; Bigston Kyokuyo (ID = 1323804) Radio
BR-600; Bigston Kyokuyo (ID = 1323806) Radio BR-600; Bigston Kyokuyo (ID = 1323807) Radio
BR-600; Bigston Kyokuyo (ID = 1323808) Radio
Use red slider bar for more.
BR-600; Bigston Kyokuyo (ID = 1323798) Radio
Bigston Kyokuyo: BR-600 [Radio] ID = 1323798 500x681
Select picture or schematic to display from thumbnails on the right and click for download.
For model BR-600, Bigston (Kyokuyo Electric Co., Ltd.); Saitama, Japan:
Ebay auction by user luttrellsonline1 120926656340

Country:  Japan
Manufacturer / Brand:  Bigston (Kyokuyo Electric Co., Ltd.); Saitama, Japan
Year: 1970 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 13: 2SC645 2SC645 2SC829 2SC829 2SC829 2SB173 2SB175 2SB175 2SB175 2SB324 2SB324 2SB172 2SB172
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details Tape Recorder
Power type and voltage Line / Batteries (any type) / 110; 120; 220; 240 / 6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: BR-600 - Bigston Kyokuyo Electric Co.,
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 11 x 11 x 3 inch / 279 x 279 x 76 mm
Notes Power supply mains and 6 volt batteries.
Source of data -- Schematic

Model page created by Antonio Barros-Regada. See "Data change" for further contributors.



All listed radios etc. from Bigston (Kyokuyo Electric Co., Ltd.); Saitama, Japan
Here you find 8 models, 8 with images and 4 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
