R710

R710 ; Bogen, David Co., (ID = 1874108) Radio

R710 ; Bogen, David Co., (ID = 1874109) Radio

R710 ; Bogen, David Co., (ID = 1874230) Radio

R710 ; Bogen, David Co., (ID = 1874231) Radio

R710 ; Bogen, David Co., (ID = 1874232) Radio

R710 ; Bogen, David Co., (ID = 1874233) Radio

R710 ; Bogen, David Co., (ID = 1874234) Radio

R710 ; Bogen, David Co., (ID = 1874235) Radio
R710 ; Bogen, David Co., (ID = 1874107) Radio
Use red slider bar for more.
R710 ; Bogen, David Co., (ID = 1874107) Radio
Bogen, David Co.,: R710 [Radio] ID = 1874107 930x538
Select picture or schematic to display from thumbnails on the right and click for download.
For model R710, Bogen, David Co., Inc.; New York (NY):
Picture from service manual.

Country:  United States of America (USA)
Manufacturer / Brand:  Bogen, David Co., Inc.; New York (NY)
Year: 1956 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 12: 12AT7 6U8 6BE6 6BA6 6AU6 6AU6 6AU6 6BJ7 12AT7 12AU7A 12AX7 6X4
Main principle Superhet with RF-stage; ZF/IF 455/10700 kHz
Tuned circuits 8 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 60 cycles, 110-120 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: R710 - Bogen, David Co., Inc.; New
Material Metal case
Shape Tablemodel, with any shape - general.
Notes

AC Operated FM - AM Superheterodyne Tuner.

Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 330 folder 4 dated 9-56.)

Model page created by Dirk Taekels. See "Data change" for further contributors.
