DO70 (D070)

DO70 ; Bogen, David Co., (ID = 2475171) Ampl/Mixer

DO70 ; Bogen, David Co., (ID = 2475173) Ampl/Mixer

DO70 ; Bogen, David Co., (ID = 2475174) Ampl/Mixer

DO70 ; Bogen, David Co., (ID = 2475175) Ampl/Mixer

DO70 ; Bogen, David Co., (ID = 2475176) Ampl/Mixer

DO70 ; Bogen, David Co., (ID = 2475178) Ampl/Mixer
DO70 ; Bogen, David Co., (ID = 997817) Ampl/Mixer DO70 ; Bogen, David Co., (ID = 997818) Ampl/Mixer
DO70 ; Bogen, David Co., (ID = 997820) Ampl/Mixer DO70 ; Bogen, David Co., (ID = 997822) Ampl/Mixer
DO70 ; Bogen, David Co., (ID = 997823) Ampl/Mixer DO70 ; Bogen, David Co., (ID = 997824) Ampl/Mixer
DO70 ; Bogen, David Co., (ID = 997825) Ampl/Mixer DO70 ; Bogen, David Co., (ID = 2475169) Ampl/Mixer
Use red slider bar for more.
DO70 ; Bogen, David Co., (ID = 997817) Ampl/Mixer
Bogen, David Co.,: DO70 [Ampl/Mixer] ID = 997817 785x482
Select picture or schematic to display from thumbnails on the right and click for download.
For model DO70 (D070), Bogen, David Co., Inc.; New York (NY):
aus ebay, #200609801150, mit Erlaubnis des Verkäufers mono

Country:  United States of America (USA)
Manufacturer / Brand:  Bogen, David Co., Inc.; New York (NY)
Year: 1956 ?? Category: Audio Amplifier or -mixer
Valves / Tubes 6: 6U8 6C4 12B4A EL34 EL34 5U4
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
Loudspeaker - This model requires external speaker(s).
Power out 70 W (unknown quality)
from Radiomuseum.org Model: DO70 - Bogen, David Co., Inc.; New
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 15.25 x 9.75 x 4.25 inch / 387 x 248 x 108 mm
Notes

David Bogen model DO70 is an AC operated audio amplifier.

Net weight (2.2 lb = 1 kg) 22.4 lb (22 lb 6.4 oz) / 10.170 kg
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 379 Folder 6 dated 11-57)

Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
