R502

R502 ; Bogen, David Co., (ID = 325961) Radio

R502 ; Bogen, David Co., (ID = 325962) Radio
Use red slider bar for more.
R502 ; Bogen, David Co., (ID = 325961) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Bogen, David Co., Inc.; New York (NY)
Year: 1950 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6SG7 6SA7 6SK7 6H6 6U5 6X5
Main principle Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: R502 - Bogen, David Co., Inc.; New
Circuit diagram reference Rider's Perpetual, Volume 18 = 1949 and before

Model page created by Egon Penker. See "Data change" for further contributors.
