T661 ; Bogen, David Co., (ID = 1610775) Radio
Bogen, David Co.,: T661 [Radio] ID = 1610775 900x520
Select picture or schematic to display from thumbnails on the right and click for download.
For model T661, Bogen, David Co., Inc.; New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  Bogen, David Co., Inc.; New York (NY)
Year: 1959 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 10: 6AB4 ECC81 6AU6 6BE6 6BA6 6AU6 6AU6 6AU6 ECC82 6X4
Main principle Superhet with RF-stage; ZF/IF 455/10700 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: T661 - Bogen, David Co., Inc.; New
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 12 x 4 x 12 inch / 305 x 102 x 305 mm
Notes

The David Bogen model T661 is a FM-AM Tuner, mono with Multiplex output; it has a Tuning Meter and AFC.

Net weight (2.2 lb = 1 kg) 19 lb 0 oz (19 lb) / 8.626 kg
Price in first year of sale 129.50 $
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date 4-59, Set 439, Folder 5)
Literature/Schematics (2) Radio Shack Catalog (1959, page 10)

Model page created by Egon Penker. See "Data change" for further contributors.



All listed radios etc. from Bogen, David Co., Inc.; New York (NY)
Here you find 207 models, 183 with images and 132 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
