SE 402

• Country
• Germany

• Manufacturer / Brand
• Braun, Karl; Nürnberg

• Year
• 1977

• Category
• Amateur TRX: Transmitter/Receiver (and Transceiver)

• Radiomuseum.org ID
• 96738

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superhet with RF-stage; ZF/IF 10700 kHz

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Line / Batteries (any type) / 220 / 12 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Metal case

• from Radiomuseum.org
• Model: SE 402 - Braun, Karl; Nürnberg

• Shape
• Tablemodel, low profile (big size).

• Notes
• Braun VHF-Transceiver SE 402.
  Frequenzbereich: 144-146 MHz; Betriebsarten: FM, SSB, CW; P_out: 10 W.
  Wie SE401, aber äußerlich geänderte Gestaltung.

• Price in first year of sale
• 2,498.00 DM

• Mentioned in
• cq-DL 6/1977

• Author
• Model page created by Otto Frosinn. See "Data change" for further contributors.
