Atelier CD5

Atelier CD5; Braun; Frankfurt (ID = 1485155) R-Player

Atelier CD5; Braun; Frankfurt (ID = 1485156) R-Player

Atelier CD5; Braun; Frankfurt (ID = 1485553) R-Player

Atelier CD5; Braun; Frankfurt (ID = 1485554) R-Player

Atelier CD5; Braun; Frankfurt (ID = 1485555) R-Player

Atelier CD5; Braun; Frankfurt (ID = 1485556) R-Player

Atelier CD5; Braun; Frankfurt (ID = 1485557) R-Player

Atelier CD5; Braun; Frankfurt (ID = 1485558) R-Player

Atelier CD5; Braun; Frankfurt (ID = 1485559) R-Player

Atelier CD5; Braun; Frankfurt (ID = 1485560) R-Player
Atelier CD5; Braun; Frankfurt (ID = 1772868) R-Player Atelier CD5; Braun; Frankfurt (ID = 1215231) R-Player
Atelier CD5; Braun; Frankfurt (ID = 1215232) R-Player Atelier CD5; Braun; Frankfurt (ID = 1359582) R-Player
Atelier CD5; Braun; Frankfurt (ID = 1591781) R-Player Atelier CD5; Braun; Frankfurt (ID = 2154671) R-Player
Use red slider bar for more.
Atelier CD5; Braun; Frankfurt (ID = 1772868) R-Player
Braun; Frankfurt: Atelier CD5 [R-Player] ID = 1772868 933x185
Select picture or schematic to display from thumbnails on the right and click for download.
For model Atelier CD5, Braun; Frankfurt:
Ebay-Verk.: suchashame, ArtNr.: 131400351511

Country:  Germany
Manufacturer / Brand:  Braun; Frankfurt
Year: 1988–1990 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details CD-Player, -Writer, MD, MOD (audio)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Atelier CD5 - Braun; Frankfurt
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 445 x 70 x 375 mm / 17.5 x 2.8 x 14.8 inch
Notes Das Spitzengerät der Atelier CD-Player: Speicher für bis zu 255 Titelfolgen, Fernbedienbarkeit, Startautomatik, digitaler Ausgang, vergoldete Buchsen, RS232-Schnittstelle, 18-Bit-8-fach-Oversampling.
Variante CD5² (CD5/2) wurde 1989-1990 produziert.
Ausführung in schwarz und kristallgrau.
Net weight (2.2 lb = 1 kg) 7.5 kg / 16 lb 8.3 oz (16.52 lb)
Price in first year of sale 2'500.00 DEM
Source of data - - Manufacturers Literature

Model page created by Günther Stabe † 19.8.20. See "Data change" for further contributors.
