• Country
• Germany

• Manufacturer / Brand
• Braun; Frankfurt

• Year
• 1980

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 141584

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Cassette Deck C301M - Braun; Frankfurt

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 500 x 110 x 330 mm / 19.7 x 4.3 x 13 inch

• Notes
• HiFi-Cassettendeck mit beleuchtetem Cassettenfach, Dolby-NR, 2 LED-Ketten, automatische Bandendabschaltung. Frequenzbereich 20-18500 Hz (Metall).
  Gehäusefarbe Schwarz oder Grau.

• Net weight (2.2 lb = 1 kg)
• 8.5 kg / 18 lb 11.6 oz (18.722 lb)

• Price in first year of sale
• 600.00 DM

• Source of data
• - - Data from my own collection

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by Werner Melichar. See "Data change" for further contributors.
