CE1020

ID = 29052

CE1020; Braun; Frankfurt (ID = 1131178) Radio

CE1020; Braun; Frankfurt (ID = 1131180) Radio

CE1020; Braun; Frankfurt (ID = 1131182) Radio

CE1020; Braun; Frankfurt (ID = 1131184) Radio

CE1020; Braun; Frankfurt (ID = 1475914) Radio

CE1020; Braun; Frankfurt (ID = 1131185) Radio

CE1020; Braun; Frankfurt (ID = 1131187) Radio

CE1020; Braun; Frankfurt (ID = 1131188) Radio

CE1020; Braun; Frankfurt (ID = 1475894) Radio

Next schematics

{gbW: "1400", gbH: "590", mW: "500", mH: "210.0", kb: "89 KB", notes: "For model CE1020, Braun; Frankfurt", title: "Braun; Frankfurt CE1020 from Jürgen Küting (1)", ite: "1"} {gbW: "933", gbH: "401", mW: "500", mH: "214.0", kb: "81 KB", notes: "For model CE1020, Braun; Frankfurt:[br]Ausführung mit seltener heller Frontblende.", title: "Braun; Frankfurt CE1020 from Bernhard Nagel (1)", ite: "1"} {gbW: "897", gbH: "700", mW: "480.0", mH: "375", kb: "119 KB", notes: "For model CE1020, Braun; Frankfurt:[br]Rechts oben der UKW-Tuner mit 4-fach Drehko-Abstimmung. FM-ZF mit drei 4-Kreis-Filtern. Stereo-Decoder und Netzteil auf unterer Platine sichtbar. Beide Platinen-Baugruppen sind über Steckkontakte verbunden.", title: "Braun; Frankfurt CE1020 from Bernhard Nagel (1)", ite: "1"} {gbW: "933", gbH: "327", mW: "500", mH: "175.0", kb: "65 KB", notes: "For model CE1020, Braun; Frankfurt", title: "Braun; Frankfurt CE1020 from Bernhard Nagel (1)", ite: "1"} {gbW: "584", gbH: "267", mW: "500", mH: "228.0", kb: "22 KB", notes: "For model CE1020, Braun; Frankfurt", title: "Braun; Frankfurt CE1020 uploaded by Bernd P. Kieck (2)", ite: "2"} {gbW: "870", gbH: "700", mW: "466.0", mH: "375", kb: "120 KB", notes: "For model CE1020, Braun; Frankfurt:[br]Ferritstab für MW/LW liegt unterhalb der HF/ZF Platte. 3 rote Kondensatoren links unten nicht original. Sie dienen der Unterdrückung von Modulationsbrumm, der v.a. bei KW- und MW-Empfang auftreten kann.", title: "Braun; Frankfurt CE1020 from Bernhard Nagel (1)", ite: "1"} {gbW: "846", gbH: "700", mW: "453.0", mH: "375", kb: "70 KB", notes: "For model CE1020, Braun; Frankfurt:[br]Bodendeckel aus Stahlblech mit Kunststoff-Abdeckung über \"magnetischen Durchlass\" für den Ferritstab.", title: "Braun; Frankfurt CE1020 from Bernhard Nagel (1)", ite: "1"} {gbW: "933", gbH: "422", mW: "500", mH: "226.0", kb: "92 KB", notes: "For model CE1020, Braun; Frankfurt", title: "Braun; Frankfurt CE1020 from Bernhard Nagel (1)", ite: "1"} {gbW: "700", gbH: "447", mW: "500", mH: "319.0", kb: "57 KB", notes: "For model CE1020, Braun; Frankfurt", title: "Braun; Frankfurt CE1020 from Bernhard Nagel (1)", ite: "1"} {gbW: "700", gbH: "228", mW: "500", mH: "162.0", kb: "18 KB", notes: "For model CE1020, Braun; Frankfurt:[br]Ebay-Verk.: kunigunde_ff, ArtNr.: 231007588474", title: "Braun; Frankfurt CE1020 uploaded by Günther Stabe † 19.8.20 (2)", ite: "2"}

CE1020; Braun; Frankfurt (ID = 491608) Radio

CE1020; Braun; Frankfurt (ID = 491610) Radio

CE1020; Braun; Frankfurt (ID = 491611) Radio

Next pictures

Use red slider bar for more.

CE1020; Braun; Frankfurt (ID = 1769141) Radio

Braun; Frankfurt: CE1020 [Radio] ID = 1769141 1400x590

Select picture or schematic to display from thumbnails on the right and click for download.

For model CE1020, Braun; Frankfurt

Country:

Germany

Manufacturer / Brand:

Braun; Frankfurt

Year: 1973–1975

Category: Broadcast Receiver - or past WW2 Tuner

Semiconductors (the count is only for transistors)

36:

Main principle	Superheterodyne (common); ZF/IF 455/10700 kHz
Tuned circuits	10 AM circuit(s) 20 FM circuit(s)
Wave bands	Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage	Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker	- For headphones or amp.
Power out
from Radiomuseum.org	Model: CE1020 - Braun; Frankfurt
Material	Metal case
Shape	Book-shelf unit.
Dimensions (WHD)	400 x 110 x 320 mm / 15.7 x 4.3 x 12.6 inch
Notes	6 ICs. Abstimmanzeige und Feldstärkeanzeige durch Instrumente. Eingebaute Ferritantenne für MW + LW, abschaltbar. Bei FM 4-fach Abstimmung, 3x 4-Kreis ZF-Filter.
Net weight (2.2 lb = 1 kg)	6 kg / 13 lb 3.5 oz (13.216 lb)
Price in first year of sale	1'200.00 DM
External source of data	Erb
Source of data	Katalog RFP 1973
