P550SX

• Country
• Germany

• Manufacturer / Brand
• Braun; Frankfurt

• Year
• 1977

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 238137

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 12

• Semiconductors

• Wave bands
• - without

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Wooden case

• from Radiomuseum.org
• Model: P550SX - Braun; Frankfurt

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 500 x 110 x 330 mm / 19.7 x 4.3 x 13 inch

• Notes

• Einbauvariante des PS 550 S. Elektronisch gesteuerter und drehzahlgeregelter Vollautomat für 33 und 45 UpM; Magnetsystem Shure M95ED; Riemenantrieb und langsam laufender Gleichstrommotor. Plattenteller 290mm Stahl 1,8 kg. Übertragungsbereich 20-20000 Hz. ICs: 8. Verbaut zum Beispiel im Braun Audio P4000

• Author
• Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
