• Year
  • 1976–1978
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 124098

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 12
  • Semiconductors
  • Wave bands
  • - without
  • Details
  • Record Player (not changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: PS550 - Braun; Frankfurt
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 500 x 110 x 330 mm / 19.7 x 4.3 x 13 inch
  • Notes
  • Elektronisch gesteuerter und drehzahlgeregelter Vollautomat für 33 und 45 UpM. Manuelle Tonarmsteuerung durch Steuerscheibe mit Sensorkontakt für elektrothermischen Lift und stufenlos wählbare Drehgeschwindigkeit des Tonarms. Riemenantrieb und langsam laufender Gleichstrommotor. Tonabnehmersystem Shure M95G.
  • Net weight (2.2 lb = 1 kg)
  • 7.3 kg / 16 lb 1.3 oz (16.079 lb)
  • Author
  • Model page created by Bernd P. Kieck. See "Data change" for further contributors.
