Stereo-Decoder TD9

Stereo-Decoder TD9; Braun; Frankfurt (ID = 506753) mod-past25

Stereo-Decoder TD9; Braun; Frankfurt (ID = 922578) mod-past25

Stereo-Decoder TD9; Braun; Frankfurt (ID = 1906435) mod-past25
Stereo-Decoder TD9; Braun; Frankfurt (ID = 1307967) mod-past25 Stereo-Decoder TD9; Braun; Frankfurt (ID = 1441668) mod-past25
Stereo-Decoder TD9; Braun; Frankfurt (ID = 1441669) mod-past25 Stereo-Decoder TD9; Braun; Frankfurt (ID = 1882400) mod-past25
Stereo-Decoder TD9; Braun; Frankfurt (ID = 1882401) mod-past25
Use red slider bar for more.
Stereo-Decoder TD9; Braun; Frankfurt (ID = 1307967) mod-past25
Braun; Frankfurt: Stereo-Decoder TD9 [mod-past25] ID = 1307967 500x311
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stereo-Decoder TD9, Braun; Frankfurt:
ebay.de Artikel 300780270356, Verkäufer ja1fr2

Country:  Germany
Manufacturer / Brand:  Braun; Frankfurt
Year: 1963/1964 Category: Radio module post 1925 (not a part, not a key)
Semiconductors (the count is only for transistors) 2: AC151 AC151 RL232g RL232g RL32g RL32g
Details
Power type and voltage Powered by external power supply or a main unit. / AC 6,3 or DC -10 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Stereo-Decoder TD9 - Braun; Frankfurt
Material Printed Circuit Board
Shape Chassis only or for «building in»
Dimensions (WHD) 130 x 25 x 70 mm / 5.1 x 1 x 2.8 inch
Notes Einfacher Schaltdecoder (Zeitmultiplex-Decoder) mit Frequenzverdoppler 19 auf 38 kHz, Schaltdioden im Ausgang, kein Stereoindikator, Betrieb an Uh 6,3 VAC oder -10 VDC.
External source of data Erb
Source of data Handbuch VDRG 1963/1964
Mentioned in -- Schematic
