Browni 2 Band Transistor 6 G - 612

Browni 2 Band Transistor 6 G - 612; CBC Charles Brown (ID = 1660451) Radio Browni 2 Band Transistor 6 G - 612; CBC Charles Brown (ID = 680951) Radio
Browni 2 Band Transistor 6 G - 612; CBC Charles Brown (ID = 680952) Radio Browni 2 Band Transistor 6 G - 612; CBC Charles Brown (ID = 680950) Radio
Browni 2 Band Transistor 6 G - 612; CBC Charles Brown (ID = 680953) Radio Browni 2 Band Transistor 6 G - 612; CBC Charles Brown (ID = 1660214) Radio
Browni 2 Band Transistor 6 G - 612; CBC Charles Brown (ID = 1660215) Radio Browni 2 Band Transistor 6 G - 612; CBC Charles Brown (ID = 1660218) Radio
Browni 2 Band Transistor 6 G - 612; CBC Charles Brown (ID = 1660219) Radio Browni 2 Band Transistor 6 G - 612; CBC Charles Brown (ID = 1660222) Radio
Use red slider bar for more.
Browni 2 Band Transistor 6 G - 612; CBC Charles Brown (ID = 1660451) Radio
CBC Charles Brown: Browni 2 Band Transistor 6 G - 612 [Radio] ID = 1660451 933x637
Select picture or schematic to display from thumbnails on the right and click for download.
For model Browni 2 Band Transistor 6 G - 612, CBC Charles Brown (Browni, Magnon, Belair); Tokyo

Country:  Japan
Manufacturer / Brand:  CBC Charles Brown (Browni, Magnon, Belair); Tokyo
Year: 1972 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6:
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage and/or dry batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 cm = 1.6 inch
Power out 0.2 W (unknown quality)
from Radiomuseum.org Model: Browni 2 Band Transistor 6 G - 612 - CBC Charles Brown Browni,
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 115 x 70.5 x 30 mm / 4.5 x 2.8 x 1.2 inch
Notes

Browni G-612 with metal front, earphone jack, jack for wire antenna. Leatherette case with strap.

Long wave: 155 - 265 kc
Medium wave: 535 - 1605 kc.

Net weight (2.2 lb = 1 kg) 0.3 kg / 0 lb 10.6 oz (0.661 lb)
Collectors' prices

Model page created by Rudolf Kernchen. See "Data change" for further contributors.
