• Country
• Japan

• Manufacturer / Brand
• CBC Charles Brown (Browni, Magnon, Belair); Tokyo

• Year
• 1965 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 155834

• Number of Transistors
• 6

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Dry Batteries / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Browni 6 Transistor 2 Band 6TP-602L - CBC Charles Brown Browni,

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 130 x 90 x 40 mm / 5.1 x 3.5 x 1.6 inch

• Notes
• Browni 6TP-602L 6 Transistor 2 Band;
  Earphones jack, LW: 150...350 KHz, black colored, metal front, brown leather carrying case known.

• Author
• Model page created by a member from A. See "Data change" for further contributors.

• Other Models

• Here you find 81 models, 74 with images and 4 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from CBC Charles Brown (Browni, Magnon, Belair); Tokyo
