RV-10A FM Tuner

RV-10A FM Tuner; Browning (ID = 1848166) Radio

RV-10A FM Tuner; Browning (ID = 1848169) Radio

RV-10A FM Tuner; Browning (ID = 1848168) Radio

RV-10A FM Tuner; Browning (ID = 1848167) Radio

RV-10A FM Tuner; Browning (ID = 1848165) Radio
RV-10A FM Tuner; Browning (ID = 1536744) Radio RV-10A FM Tuner; Browning (ID = 1536745) Radio
RV-10A FM Tuner; Browning (ID = 1536746) Radio RV-10A FM Tuner; Browning (ID = 209224) Radio
RV-10A FM Tuner; Browning (ID = 1536747) Radio
Use red slider bar for more.
RV-10A FM Tuner; Browning (ID = 1536744) Radio
Browning: RV-10A FM Tuner [Radio] ID = 1536744 933x772
Select picture or schematic to display from thumbnails on the right and click for download.
For model RV-10A FM Tuner, Browning Laboratories Inc.; USA:
aus ebay, #221285417421, Verkäufer stealthb7

Country:  United States of America (USA)
Manufacturer / Brand:  Browning Laboratories Inc.; USA
Year: 1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 10: 6AU6 7F8 6AU6 6AU6 6SJ7 6SJ7 6H6 6J6 6AL7 5Y3GT
Main principle Superheterodyne (common); ZF/IF 10700 kHz
Wave bands FM Broadcast Band Only
Details
Power type and voltage Alternating Current supply (AC) / 110-120 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: RV-10A FM Tuner - Browning Laboratories Inc.;
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 11 x 8.75 x 6.5 inch / 279 x 222 x 165 mm
Notes

Mono tuner with A.F.C. Tuning Range 88 - 108 MHz (MC).

Price in first year of sale 95.00 $
Mentioned in Photofact Folder, Howard W. SAMS (Date 5-1951, Set 131, Folder 3)
Literature/Schematics (1) 1951 Newark catalog Nº 51

Model page created by Vitor Oliveira. See "Data change" for further contributors.



All listed radios etc. from Browning Laboratories Inc.; USA
Here you find 55 models, 42 with images and 18 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
